Wireless 1.5U rack mounted Video Data Links for Radio Communications Other Security Product

Name: Wireless 15U rack mounted Video Data Links for Radio Communications Other Security Product
Brand: Ding Shen
Price: 1 USD

Quality Wireless 1.5U rack mounted Video Data Links for Radio Communications Other Security Product wholesale

Brand Name : Ding Shen

Model Number : DS-HR50

Place of Origin : China

MOQ : 1 Set

Price : negotiation

Payment Terms : T/T

Supply Ability : 3,000pcs per month

Delivery Time : 3-7 works days

Packaging Details : International packing

Modulation : COFDM 2K, qpsk

Video compression : H.264/MPEG-2(autoadaptation)

Carrier : 2K, 4k

Product name : Radio Communications

Type : audio video receiver, digital cofdm receiver

Decryption : AES user configured passwords

Contact Now

DS-HR50 is a vehicle-mounted high-definition H.264 COFDM wireless video audio receiver, standard 1.5U rack designed, simple and efficient to use control panel. Support output video (including HD and SD resolution) audio signal simultaneously. It has the strong anti-jamming capacity, overcomes the reflection and cover caused by transmission multipath simulation technique and conventional modulation techniques, to realize high-speed photography and real-time receive high quality image in NLOS(Non-Line-of Sight) or complicated working environment. Easy to place it in vehicle and room for video monitoring.

Features:

1.NLOS & LOS

2.long range wireless audio video reception

3.digital

4.OFDM modulation

5.720P or HD1080P real time broadcast

6.BNC connectors for SD

7.HD or SDI for HD

Specification

Frequency	300~4400Mhz(optional)
RF bandwidth	2/2.5/4/8MHz(adjustable),4/8MHz is for HD resolution
Receive sensitivity	-105dBm/2MHz, -95dbm/4MHz/8MHz
Working Voltage	DC12V/AC220V
Working current	1.5A
Power consumption	≤20W
Modulation	COFDM 2K QPSK
Constellation	QPSK,16QAM,64QAM
AV Interface	BNC
HD output	HD
Audio channel	stereo left and right channels
RF Interface	N F head (50Ω)
FEC	1/2, 2/3, 3/4, 7/8
Guard Interval	1/32, 1/16, 1/8, 1/4
Resolution	1920*1080, 720P, 576, 480
Data Encryption	AES 128 Bits
Video format	PAL/NTSC(self adaption)
Operating temperature	-30~70℃
Physical dimension	1.5U
Weight	3.5KG
Size	48022044mm

Wireless 1.5U rack mounted Video Data Links for Radio Communications Other Security Product

Application

Wireless 1.5U rack mounted Video Data Links for Radio Communications Other Security Product

Wireless 1.5U rack mounted Video Data Links for Radio Communications Other Security Product Images
